SPECIFICATIONS:
TYPE | UNIT | QMT09A03 |
Min. Sound Output at 10cm | dB | 85 |
Rated Voltage | V0-p | 3 |
Operating Voltage | V0-p | 2~4 |
Resonant Frequency | Hz | 2730 |
Max. Current Consumption | mA | 70 |
Coil Resistance | Ω | 16±2 |
Operating Temperature | ℃ | -20~+70 |
Storage Temperature | ℃ | -30~+80 |
Weight | g | 0.7 |
Value applying at (rated voltage, 2730 Hz, 1/2 duty square wave)
